34CrNiMo6 SAE4340 Forged Steel Square Flat Bar Steel Block VCN150 Dimension 75*520*680mm
34CrNiMo6 SAE4340 Forged Steel Square Flat Bar Steel Block VCN150 Dimension 75*520*680mm
34CrNiMo6 SAE4340 Forged Steel Square Flat Bar Steel Block VCN150 Dimension 75*520*680mm
34CrNiMo6 SAE4340 Forged Steel Square Flat Bar Steel Block VCN150 Dimension 75*520*680mm
34CrNiMo6 SAE4340 Forged Steel Square Flat Bar Steel Block VCN150 Dimension 75*520*680mm
34CrNiMo6 SAE4340 Forged Steel Square Flat Bar Steel Block VCN150 Dimension 75 * 520 * 680mm
Raws li tus neeg muag khoom thiab chaw tsim khoom nyob rau hauv Suav teb, GNEE Steel muab tus nqi -nickel zoo- raws li cov khoom siv alloy.
- Xa E-mail:ss@gneesteel.com
- Tel:+8615824687445
34CrNiMo6 SAE4340 Forged Steel Square Flat Bar Steel Block VCN150 Dimension 75 * 520 * 680mm
Kev piav qhia
| Cov txheej txheem: | Kub Rolled Forged | Txheem: | ASTM DIN EN |
|---|---|---|---|
| Ntev: | 1000-12000 hli | Qib: | Alloy Steel Square tiaj tus Bar |
| Nto: | Dub | Khoom siv: | Alloy Steel Qauv |
| Nqe Sijhawm: | CIF CFR FOB EX-WORK |
34CrNiMo6 SAE4340 Forged Steel Square Flat Bar Steel Block VCN150 Dimension 75 * 520 * 680mm
1: 34CrNiMo6 steel kev taw qhia
34CrNiMo6 hlauyog ib qho tseem ceeb alloy engineering steel qib raws li BS EN 10083-3: 2006. 34CrNim06 steel muaj lub zog siab, siab toughness thiab zoo hardenability. EN / DIN 34CrNiMo6 alloy hlau muaj kev ruaj ntseg ntawm kev tiv thaiv overheating, tab sis cov dawb rhiab heev ntawm 34CrNiM06 yog siab. Nws kuj muaj qhov kub thiab txias, yog li lub weldability ntawm 34CrNiMo6 cov khoom tsis zoo. Cov hlau 34CrNiMo6 xav tau qhov kub thiab txias ua ntej vuam txhawm rau txhawm rau tshem tawm cov kev ntxhov siab tom qab vuam ua haujlwm.
2: 34CrNiMo6 hlau sib npaug
| Lub teb chaws | Lub teb chaws Yelemees | Teb chaws USA |
| Txuj | EN 10083-3 | ASTM A29 |
| Qib | 34CrNiMo6/1.6582 | 4337 |
3: 34CrNiMo6 steel tshuaj muaj pes tsawg leeg
| Qib | C | Si | Mn | P | S | Cr | Mo | Ni |
| 4337 | 0.3-0.4 | 0.2-0.35 | 0.6-0.8 | 0.035 | 0.04 | 0.7-0.9 | 0.2-0.3 | 1.65-2.0 |
| 34 CrNiMo6 | 0.3-0.38 | 0.4 | 0.5-0.8 | 0.025 | 0.035 | 1.3-1.7 | 0.15-0.3 | 1.3-1.7 |
4: 34CrNiMo6 steel mechanical zog
Cov khoom siv tshuab feem ntau suav nrog lub zog tensile, lub zog tawm los, elongation, cheeb tsam lossis txo qis, hardness, cuam tshuam tus nqi, tsis yog xim hlau suav nrog thiab lwm yam. Kev kho cua sov sib txawv, cov khoom siv kho tshuab yuav txawv, xws li normalized, tempered, QT. Yog tias koj xav paub cov khoom, thov hu rau tus neeg muag khoom.
5: 34CrNiMo6 steel txheej txheem cej luam
| Loj | Hloov | Dia 6-1200mm |
| Phaj / tiaj / thaiv | Thickness 6mm -500 hli |
|
| Dav 20mm -1000 hli |
||
| Kev kho cua sov | normalized; Annealed; Quenched; Tempered | |
| Deg mob | Dub; Peeled; Polished; Tshuab; Sib tsoo; tig; Milled | |
| Kev xa khoom | Forged; Kub dov; Txias kos | |
| Kuaj | Tensile zog, Yield zog, elongation, cheeb tsam ntawm txo, cuam tshuam tus nqi, hardness, grain loj, ultrasonic kuaj, US soj ntsuam, magnetic particle kuaj, thiab lwm yam. | |
| Cov nqe lus them nqi | T / T; L / C; / Nyiaj Gram / Paypal | |
| Cov ntsiab lus lag luam | FOB; CIF; C&F; lwm.. | |
| Lub sij hawm xa tuaj | 30-45 hnub | |
| Daim ntawv thov | 34 CrNiMo6yog siv rau hnyav machinery qag, turbine ncej hniav, siab load ntawm kis tau tus mob qhov chaw, fasteners, crankshafts, zog, raws li zoo raws li hnyav loaded qhov chaw rau lub cev muaj zog siv thiab lwm yam. | |
6: Kev xa khoom xa tuaj
Rau qhov kub forged bar, feem ntau cov khoom xa tuaj yog kub forged, annealed ntxhib tig / Dub nto.
Rau kub dov bar, feem ntau cov khoom xa tuaj yog kub dov, annealed, Dub nto.
Rau kub forged phaj, feem ntau tus me nyuam mob yog kub forged, annealed, milled nto
Rau kub dov phaj, feem ntau qhov kev xa khoom yog kub dov, annealed, dub nto.
Cim npe nrov: 34crnimo6 sae4340 forged steel square flat bar steel block vcn150 dimension 75 * 520 * 680mm, Tuam Tshoj 34crnimo6 sae4340 forged steel square flat bar steel block vcn150 dimension 75 * 520 * 680mm lwm tus neeg
