Alloy Steel Round Bar Qws DIN 18CrNiMo7-6 1.6587 Tshuaj Annealing Q+T
Raws li tus neeg muag khoom thiab chaw tsim khoom nyob rau hauv Suav teb, GNEE Steel muab tus nqi -nickel zoo- raws li cov khoom siv alloy.
- Xa E-mail:ss@gneesteel.com
- Tel:+8615824687445
Alloy Steel Round Bar Qws DIN 18CrNiMo7-6 1.6587 Tshuaj Annealing Q+T
Kev piav qhia
| Steel Qib: | Hlau alloy | Alloy los yog Tsis: | Yog Alloy |
|---|---|---|---|
| Cov txheej txheem: | Kub Rolled, Forged | Daim ntawv thov: | Cov cuab yeej Steel Bar |
| Hom: | Alloy Steel Bar, Pwm Hlau, siab ceev cuab yeej hlau | Txheem: | ASTM, DIN, AISI, JIS |
| Cov duab: | Hloov | Ntev: | 1--12m |
| Kev kho deg: | Dub / Peeling / Polishing / Machined | Txoj kab uas hla: | 12mm -650 hli |
| Delivery condition: | Annealed, Kub Rolled / forged | Qhov Loj: | 5-900MM |
| Kev kho cua sov: | Normalized + Annealed + Quenched + Tempered | ||
| Lub teeb siab: |
Kev daws Annealing Steel Round Bar Qws,900MM Hlau Round Bar Qws,Hlau Round Bar Qws 650mm |
||
17CrNiMo7-6 Alloy Steel Round Bar DIN 18CrNiMo7-6 1.6587 Solution Annealing Q+T Alloy Qws
18CrNiMo7-6 Round Bar - Case-Hardened Steel - Din 17210 EN 10084
Daim ntawv thov
18CrNiMo7-6 puag ncig Bar - Case-Hardened Steel feem ntau yog siv rau hauv cov khoom siv kho tshuab, tsheb qhov chaw, cement nroj tsuag, fais fab nroj tsuag, mobile cranes thiab lub ntiaj teb txav khoom, ntawv zeb, suab thaj zeb, marine, cua iav, roj platform, Kev tiv thaiv hluav taws, kev kho mob, khoom siv hauv kev lag luam, collets, cams, rollers, bushes, spindles, thiab gears, thiab lwm yam.
Txuj kev zoo
-BS EN 10084-2008 Case hardening steels.
-DIN 17210 rau Case hardening steel.
Qib Steel
EN DIN ANFOR
18CrNiMo7-6 1 6587 18NCD6
Chemical Composition (%)
| C | Si | Mn | P | S | Cr | Mo | Ni |
| 0.15-0.21 | 0.40 max | 0.50-0.90 | 0.025 max | 0.025 max | 1.50-1.80 | 0.25-0.35 | 1.40-1.70 |
Mechanical Properties
| Txheej txheem | Tensile zog Rm (Mpa) | Yield zog Rp 0.2 (Mpa) | Elongation A5 (%) | Thaj tsam txo qis C (%) | Hardness (HB) |
| Annealed | / | / | / | / | 229 max |
| Li qub | / | / | / | / | 140-210 |
| Q+T | 980-1270 | 685 nqi | 8 feeb | 35 feeb | 295-373 |
Kev kho cua sov
Annealing: Kub 18CrNiMo7-6 mus rau 650-700 degree, txias maj mam hauv qhov cub.
Normalizing: 850-880 degree, huab cua.
Hardening: Carburising: 880-980 degree . Core Hardening: 830-870 degree, dej. Case Hardening: 780-820 degree, dej.
Tempering: 150-200 degree .
Muaj peev xwm
3,000 tuj ib hlis.
Kuaj
Tshuaj ntsuam xyuas, Mechanical analysis, Ultrasonic testing, Metallographic, Surface quality and dimension report.
Pob
Txhua pob ntawm max 3,000kg nrog ob peb steel strips, Ob lub cim npe ntawm txhua lub nras, qhwv hauv cov ntawv tsis muaj dej, PVC lub tes tsho, thiab cov hnab ev khoom nrog ob peb lub tsho hlau.
Mill's Test Certificate
TS EN 10204 / 3.1 Cov ntaub ntawv tsim nyog chem. kev, mech. cov khoom thiab cov txiaj ntsig ntawm kev sim.
