CS Seamless Steel Yeeb Nkab Raws li ASME / SA179 100 % HY kuaj tag nrho cov raj nrog cim



CS Seamless Steel Yeeb Nkab Raws li ASME / SA179 100 % HY kuaj tag nrho cov raj nrog cim

Kev piav qhia

OD:	6-159MM	Thickness:	1-50 hli
Ntev:	1-12m	Nto:	Dub Thiab Bright
Hom:	Seamless
Lub teeb siab:	carbon steel seamless yeeb nkab , structural steel kav

CS Seamless Tube li ASME/SA179 100 % HY Tested Tag nrho Tube Nrog Kos Cov Cuab Yeej Cuab Yeej

Cov ntsiab lus ceev:



Txuj: ASTM A179 (ASME SA179)

Qib: A179 SA179

Loj: (mm)

OD: 6mm txog 114mm;

WT: 0.5mm txog 15mm;

Ntev: 6m ~ 25m



Related Specification Paub meej:



Lub npe	SA179 txias kos ncaj seamless steel hlab thiab kav
Txuj	Ua tau raws li lossis tshaj ASTM, ASME, API, ANSI thiab DIN cov qauv. ASTM A106 / A179 / A192 / A210 / A213 / A519 thiab lwm yam. DIN2391 / DIN17175 / EN10305 thiab lwm yam GB8162 / GB8163 / GB3639 thiab lwm yam
Khoom siv	A179, 35, 45, 52, E215, E235, E355, 10, 20, A106, A179, A192, A210, T11, T22, T12 thiab lwm yam
Loj	Sab nraud txoj kab uas hla: {{0}}.0mm Phab ntsa thickness: 0 5-15mm Ntev: max 2400mm, feem ntau 6000mm
Daim ntawv thov	Txias los yog txias dov precision seamless steel raj rau hydraulic siab thiab pneumatic kev pabcuam. Kev siv nws pib, kev siv tshuab, roj lub tog raj kheej raj, kev siv lub tsheb kauj vab txo qis, nws pib poob siab reducer puab lub tog raj kheej, thiab lwm yam.   Seamless steel kav rau qis thiab nruab nrab siab boiler, siab siab boiler, nkoj-tsev, Kev pabcuam ua kua, roj av tawg, cov khoom siv tshuaj chiv, kos duab-roj-cov khoom siv thiab cov hom phiaj.
Kev lag luam Scope	DIN series txias kos precision seamless steel raj DIN series txias dov precision seamless steel raj Related coated thiab galvanized steel raj Rustproof phosphyorylated raj
Lub ntsiab yam ntxwv	Tsis muaj Oxidation Txheej ntawm cov phab ntsa sab nrauv thiab sab hauv; Tsis muaj dej ntws los ntawm kev kub siab; Tsis muaj Crake nyob rau hauv flatting thiab flattening; Tsis muaj distortion tom qab txias dabtsi yog khoov; High precision siab huv; brightness zoo heev txias kos thiab kub tiav Kev ua tau zoo tshaj plaws rau kev siv siab thiab kub Dub tag thiab kub dip galvanized Zoo heev corrosion kuj





Qib thiab Chemical Composition (%):



STANDARD	QIB	CHEMICAL COMPOSITION
		C	Si	Mn	P	S	Cr	Mo	Cu	Ni	V
ASTM A179 Cov khoom lag luam	A179	Tsawg dua lossis sib npaug rau 0.06-0.18	/	0.27-0.63	Tsawg dua lossis sib npaug rau 0.035	Tsawg dua lossis sib npaug rau 0.035
ASME SA106	SIB 106B	0.170.25	Ntau dua lossis sib npaug rau 0.1	0.701.00	Tsawg dua lossis sib npaug rau 0.030	Tsawg dua lossis sib npaug rau 0.030	Tsawg dua lossis sib npaug rau 0.035
ASTM A106 1	A	Tsawg dua lossis sib npaug rau 0.25	Tsawg dua lossis sib npaug rau 0.10	0.270.93	Tsawg dua lossis sib npaug rau 0.035	Tsawg dua lossis sib npaug rau 0.035	Tsawg dua lossis sib npaug rau 0.40	Tsawg dua lossis sib npaug rau 0.15	Tsawg dua lossis sib npaug rau 0.40	Tsawg dua lossis sib npaug rau 0.40	Tsawg dua lossis sib npaug rau 0.08
	B	Tsawg dua lossis sib npaug rau 0.30	Tsawg dua lossis sib npaug rau 0.10	0.291.06	Tsawg dua lossis sib npaug rau 0.035	Tsawg dua lossis sib npaug rau 0.035	Tsawg dua lossis sib npaug rau 0.40	Tsawg dua lossis sib npaug rau 0.15	Tsawg dua lossis sib npaug rau 0.40	Tsawg dua lossis sib npaug rau 0.40	Tsawg dua lossis sib npaug rau 0.08
	C	Tsawg dua lossis sib npaug rau 0.35	Tsawg dua lossis sib npaug rau 0.10	0.291.06	Tsawg dua lossis sib npaug rau 0.035	Tsawg dua lossis sib npaug rau 0.035	Tsawg dua lossis sib npaug rau 0.40	Tsawg dua lossis sib npaug rau 0.15	Tsawg dua lossis sib npaug rau 0.40	Tsawg dua lossis sib npaug rau 0.40	Tsawg dua lossis sib npaug rau 0.08
ASTM A53	A	0.25	/	0.95	0.05	0.045	0.40	0.15	0.40	0.40	0.08
	B	0.3	/	1.2	0.05	0.045	0.40	0.15	0.40	0.40	0.08



Mechanical Properties:



Mechanical zog
Khoom siv	Min Tensile zog N / hli 2	Min. Yield zog N / hli 2	Min Elongation %
A179	325	180	35



Tolerance Control:



OD hauv (mm)	+	-	WT hauv (mm)	+	-
<1(25.4)	0.10	0.10	Tsawg dua los yog sib npaug rau 1.1/2(38.1)	20%	0
1∼1.1/2(25.4∼38.1)	0.15	0.15	>1.1/2(38.1)	22%	0
>1.1/2∼<2(38.1∼50.8)	0.20	0.20	/	/	/
2∼<2.1/2(50.8∼63.5)	0.25	0.25	/	/	/
2.1/2∼<3(63.5∼76.2)	0.30	0.30	/	/	/
3∼4(76.2∼101.6)	0.38	0.38	/	/	/

Nqe lus piav qhia:



Khoom npe: ASME SA179 / SA179M seamless carbon steel yeeb nkab

Txuj: ASME SA179 SA179M, ASTM DIN JIS lossis GB txuj

Sab nraud txoj kab uas hla: 6mm ~ 114 0mm

Phab ntsa Thickness: 0.5mm ~ 15mm

Ntev: 6m-24m, kuj tuaj yeem tsim tau raws li cov neeg siv khoom xav tau

Hom: Seamless (txias kos)

Ends: Plain xaus los yog bevel xaus

Kev Xa Khoom: BK, BKS, BKW, NBK, GBK (Raws li kos, quenched thiab tempered, normalized, annealed, stress-relieved) Raws li cov kev cai sib txawv, Nws suav nrog pickling, thiab lwm yam. AS rau Standard.

Txheej rau kev tiv thaiv: dub painting, anti-xeb oiled los yog kua roj vanish, kuj yuav tsum tau raws li cov neeg muas zaub 'yuav tsum tau





Factory xeem thiab lwm cov nqe lus:



1.Hydrostatic lossis Nondestructive Electric Test

2. Kev kho cua sov: raws li Standard
3.Surface Condition: Raws li Standard.
4.Grain Size: Raws li tus qauv
5.Sampling: flattening, flaring, nplej loj, Marking

6.we muab bevel kawg, yas hau, kua roj vanish txheej, oiled los yog dub pleev xim rau kom tiv thaiv rustand lwm packing

kev pabcuam.





Daim ntawv thov:



1, Rau evaporator, tshav kub exchangers, condensers, hloov cov khoom cua sov thiab cov kav dej zoo sib xws.

2, Siv dav hauv kev kho tshuab kho tshuab, kev lag luam petrochemical, kev thauj mus los thiab kev tsim kho

3, Ordinary structural purposes thiab mechanical structural purposes, piv txwv li hauv kev tsim kho, fulcrum bearing thiab lwm yam;

4, Kev thauj mus los ntawm cov kua hauv cov haujlwm thiab cov khoom siv loj, piv txwv li kev thauj dej, roj, roj thiab lwm yam

5, tuaj yeem siv rau hauv qhov qis thiab nruab nrab siab boiler rau kev thauj mus los ntawm cov kua, piv txwv li chav tube, cov pa luam yeeb loj, cov pa luam yeeb me me, tsim cov raj thiab lwm yam.
