Inconel 601 Phaj (UNS N06601 / W.Nr. 2.4851) yog dab tsi?
Inconel 601 (UNS N06601, W.Nr.2.4851)yog ib qho kev daws-txhim kho Ni-Cr-Fe-Al nickel-based superalloy. Ua tsaug rau kev tiv thaiv oxide zaj duab xis tsim los ntawm chromium thiab txhuas, nws nta zoo heev oxidation kub, carburization thiab sulfidation kuj. Nws muaj kev ua haujlwm zoo, weldability thiab siab-kub txhua yam muaj zog. Nws yog dav siv rau lub cub tawg radiant raj, kho cua sov fixtures, tshuaj thermal reactors, lub zog-tsim kho vajtse thiab aerospace gas-turbine qhov chaw rau 500-1150℃kev pab cuam tej yam kev mob
Xav paub seb UNS N06601 phaj tuaj yeem daws koj cov teeb meem oxidation-corrosion? Scroll cia rau tag nrho cov lus qhia.
Tiv tauj peb tam sim no rau tus nqi tshiab tshaj tawm ntawm Inconel 601 npib tsib xee alloy phaj.
Inconel 601 Phaj (UNS N06601) Specifications & Srtandard
| Yam khoom | Specification / Txuj |
| Thickness Ntau | 2.5mm-50mm(Rau qhov tuab <2.5 hli, thov xa mus rau Inconel 601 Nickel Alloy Sheet) |
| Dav Ntau | 50mm-2000 hli |
| Ntev | 100mm-6000mm |
| Custom Size | Raws li kev pom zoo nrog peb pab neeg |
| Manufacturing Standards | ASTM B168 / ASME SB 168 / DIN 17750 / EN 10095 / ISO 6208 |
| Kev Xa Khoom | Kub Rolled |
| Nto tiav | No.1, 1D, Pickled, lossis customized raws li kev thov |
Qhov zoo ntawm Inconel 601 Superalloy Medium Thick Phaj
Zoo heev kub-kub oxidation kuj:
Cr-Al cov ntsiab lus tsim ntom ntom ntom tiv thaiv oxide nplai. Nws tuaj yeem tiv taus qhov kub txog li 1200 degree, thiab oxide nplai tsis tshua muaj qhov sib txawv hauv cov voj voog thermal rau kev pabcuam ntev.
Superior carburization & nitridation kuj:
Nyob rau hauv carburizing los yog nitriding cua ntawm cov cua kub-kho qhov cub, nws thaiv cov pa roj carbon-nitrogen nkag mus rau tiv thaiv brittleness thiab muab lub neej kev pab cuam ntev dua li ntau cov nickel-based daim hlau.
Cov cuab yeej kho tshuab ruaj khov ntawm qhov kub thiab txias:
Nrog ruaj khov-solution metallurgical qauv, nws tuav lub zog zoo-ductility nyob rau hauv chav tsev thiab kub, txo kev pheej hmoo ntawm deformation thiab tawg nyob rau hauv thermal-stress load.
Comprehensive kub & aqueous corrosion kuj:
Nickel-chromium matrix resists ntau yam kub-kub muaj corrosive atmospheres nrog rau aqueous corrosion, adapting rau nyuaj corrosive tej yam kev mob nyob rau hauv tshuaj thiab lub zog industries.
Txhim khu kev sib sau thiab vuam kev ua tau zoo:
Lub phaj txhawb kev kub thiab txias. Cov txheej txheem welding yog siv tau; Kev kho cua sov tom qab vuam yog feem ntau tsis tsim nyog rau kev txiav yooj yim, dov thiab ntawm qhov chaw tsim khoom.
Inconel 601 Phaj (UNS N06601) Tshuaj muaj pes tsawg leeg
| Qib | Txuj | C | Si | Mn | Cu | S | Cr | Ni | Al |
| Inconel 601 | ASTM B 163 | Tsawg dua lossis sib npaug li 0.10 | Tsawg dua los yog sib npaug li 0.50 | Tsawg dua lossis sib npaug li 1.00 | Tsawg dua lossis sib npaug li 1.00 | Tsawg dua lossis sib npaug li 0.015 | 21.00-25.00 | 58.0-63.0 | 1.00-1.70 |
Inconel 601 Phaj (UNS N06601) Mechanical Properties
| Qhov ntom | Melting Point | Tensile zog | Yield zog (0.2% Offset) | Elongation |
| 8.11 g / cm3 | 1411℃(2571℃F) | 550-1310 Mpa | 205-1205 Mpa | 70% – 2% |
Inconel 601 Phaj (UNS N06601) Lub cev muaj zog
| Melting Range | Cov cua kub tshwj xeeb, 20℃(J / (gK)) | Sib nqus permeability (20 degree) | Thermal conductivity, 20℃(W / (mK)) | Curie Kub (degree) |
| 1411℃(2571℃F) | 448 | ＜1.003 | 11.2 | -196 |
Inconel 601 Phaj (UNS N06601) Daim duab & Formula
Formula: m=W (m) × THK (mm) × L (m) × ρ (g/cm³)
W=Dav, THK=Thickness, L=Length, ρ=Ceev
Piv txwv
Peb muab Inconel 601 phaj: Thickness=10 mm, Dav=1.5 m, Length=3 m, ntom=8.11 g/cm³
m=1.5x 10x3x 8.11=364.95 kg
Nyem kom tau Inconel 601 phau ntawv hnyav.
Koj tuaj yeem sau koj tus kheej qhov loj me: thickness (mm), dav (m), ntev (m). Muab lawv los ntawm 8.11 kom tau txais qhov ntsuas qhov ntsuas ntawm Inconel 601 phaj.
Yuav Ua Li Cas Tshuab & Fabricate Inconel 601 Nickel Alloy Phaj?
Melting txheej txheem ntawm Inconel 601 phaj
Vacuum Induction Melting (VIM) + Nqus Arc Remelting (VAR). Kev tswj tshuaj nruj nruj ntawm Ni-Cr-Al-Fe nrog cov impurities tsawg rau cov khoom zoo sib xws.
Kub Rolling rau Inconel 601 phaj
Ingot kub dov ntawm 1050-1150 degree. Kev tswj qhov kub thiab txias kom tau lub hom phiaj tuab thiab dav rau cov phaj kub dov.
Kev kho mob ntawm Inconel 601 phaj
Kev daws annealing ntawm 1100-1175℃nrog ceev txias. Dissolve carbides, homogenize grain qauv thiab rov ductility & oxidation kuj.
Nto Finishing rau Inconel 601 phaj
Txhaj tshuaj tua kab mob rau kev tshem tawm hnyav, ua raws li HF-HNO₃ pickling thiab ntug sib tsoo rau tus qauv No.1 tiav lawm.
Precision Txiav ntawm Inconel 601 phaj
Plasma lossis dej dav hlau txiav rau qhov loj me. Deburring thiab trimming rau tiav phaj loj.
Kev tshuaj xyuas & xa khoom rau Inconel 601 phaj
PMI, UT non-destructive test, mechanical inspection. Tshaj tawm 3.1 cov ntaub ntawv pov thawj nrog seaworthy export ntim.
Daim ntawv thov ntawm Inconel 601 Oxidation-Resistant Alloy Phaj
Rauv siv ntawm Inconel 601 phaj
Fabricate furnace radiant tubes, furnace rollers, material racks, heat-treatment fixtures, muffle liners thiab annealing furnace linings. Tiv thaiv cyclic thermal shock, kub-kub oxidation thiab carburization.
Petrochemical Parts rau Inconel 601 phaj
Cracking furnace coils, catalytic transforming reactors, high-temperature heat exchange parts thiab incinerator liners. Kev pabcuam rau flue gas, sulfidation thiab oxidative corrosive media.
Fais fab-Tsim siv rau Inconel 601 phaj
Boiler superheater Cheebtsam, roj turbine tshav kub shields, pov tseg-rau-zog boiler qhov chaw thiab biomass hwj chim siab-kub resistant sib dhos.
Aerospace Cheebtsam ntawm Inconel 601 phaj
Aero-engine combustion baffles, ducts thiab high-temperature guide vanes rau cyclic kev pab cuam ntawm 600-1150 degree.
Daim ntawv thov Metallurgy ntawm Inconel 601 phaj
Sintering furnace trays, refractory txhawb thav ntawv thiab iav rauv khoom, tswj kev ruaj ntseg nyob rau hauv tas li oxidative high-temperature cua.
Cov Khoom Siv Hluav Taws Xob nrog Inconel 601 phaj
SCR high-temperature baffles rau flue-gas denitrification, high-temperature plua plav-collector plhaub thiab thermal oxidizer khoom tiv thaiv flue-gas corrosion thiab oxidation.
Inconel 601 (UNS N06601 / W.Nr. 2.4851) Cov Khoom Siv & Cov Khoom Siv Zeb
| Cov Qauv Khoom | Cov qauv |
|---|---|
| Qws, Bar & Hlau | ASTM B166 |
| Phaj, Sheet & Sawb | ASTM B168, ASTM B906 |
| Seamless Yeeb Nkab thiab Tube | Raws li ASTM B167, ASTM B829 |
| Welded yeeb nkab | ASTM B775 Cov Lus Qhia Tshwj Xeeb |
| Welded Tube | ASTM B751 Cov Lus Qhia Tshwj Xeeb |
Cov Qauv Khoom & Cov Qauv Txheej Txheem
Vim li cas thiaj xaiv GNEE ua koj tus khub koom nrog?
✅️Npaj Cov Khoom Muag & Cov Khoom Muag: Cov khoom lag luam 40+ cov qib nickel alloy tseem ceeb, npog Monel, Inconel, Incoloy, thiab Hastelloy series muaj nyob rau hauv daim hlau, tuav, kav, thiab forging billets. Standard Tshuag khoom lub sij hawm yog7-10 hnub ua haujlwm, thaum kev cai tsis yog - qhov loj me yuav tsum tau25-30 hnub ua haujlwm. Peb txhawb kev sib xyaw ua ke - qib ntim khoom xa tuaj nrog xoom yuav tsum muaj MOQ loj.
✅️Quality & Inspection Services: Txhua batch undergoes100% tag nrho- tshuaj xyuas yam khoom, suav nrog OES tshuaj ntsuam xyuas, ntsuas cov cuab yeej cuab tam, kev txheeb xyuas qhov ntev, thiab kev txheeb xyuas cov khoom siv PMI. Daim phiaj thiab puag ncig tuav tau txais100% Kev Ntsuas Ultrasonic (UT). Thib peb- tog neeg pov thawj tshuaj xyuas los ntawmSGS, BV, los yog TÜVtau txais kev txhawb nqa thaum thov. Tag nrho cov ntaub ntawv tshuaj xyuas tau muab khaws cia rau tsawg kawg 5 xyoo kom paub meej tias kev ua tiav tiav.
✅️Export Ntim & Logistics: Ua tiav alloys feature4-txheej dej hiav txwv export ntim: VCI anti-xeb ntawv, PE zaj duab xis waterproof, galvanized steel wrapping, thiab ISPM-15 fumigated ntoo pallets ruaj nrog hnyav- lub luag haujlwm steel strapping. Peb txhawb nqa hiav txwv, tsheb ciav hlau, thiab huab cua thauj khoom, muab ua ntej- nkoj thauj khoom thauj cov duab. Max ntev: 6 meters rau 20ft thawv thiab 12 meters rau 40ft thawv, txhawb nqa los ntawm cov khoom xa tuaj raws sijhawm.
✅️Kev Pab Txhawb Cov Neeg Siv Khoom: Peb pab neeg ua haujlwm teb rau txhua qhov kev nug hauv24 teev ua haujlwm, muab kev xaiv qib alloy, vuam kev taw qhia, thiab kev pabcuam txiav. Order qhov ntau thiab tsawg los ntawm5 kg qauv txiav txim rau tag nrho cov thawv loads (FCL). Rov qab los ntawm18 xyoo tshwj xeeb alloy export kevua haujlwm rau cov neeg siv khoom thoob plaws 40+ lub teb chaws, peb ib qho - nres kev pabcuam suav nrog kev tshuaj xyuas kev kos duab, kev taug qab ntau lawm, kev soj ntsuam xyuas, thiab ua tiav cov ntaub ntawv xa tawm.
✅️Cov ntaub ntawv pov thawj & Traceability: Txhua qhov khoom xa tuaj suav nrog kev ua haujlwmEN 10204 3.1 Mill Test Certificate (MTC), nrogEN 10204 3.2 thib peb- daim ntawv pov thawj togmuaj nyob rau ntawm qhov kev thov. Tag nrho cov khoom nruj me ntsis ua raws li ASTM, AMS, thiab GB / T qauv raws li pebISO 9001 Kev Tswj Xyuas Qhov Zoo. Cov ntawv pov thawj raug txuas cov lej xov tooj cua sov, cov tshuaj muaj pes tsawg leeg, cov khoom siv kho tshuab, thiab cov ntaub ntawv kho cua sov rau cov khoom siv lub cev rau qhov kawg - mus rau - kawg traceability los ntawm melting mus rau qhov kawg xa.
GNEE muab cov khoom siv ntau lawm.
Yuav Ua Li Cas Yuav Inconel 601 Phaj?
Thaum muas Inconel Alloy 601 phaj, npaj cov ntaub ntawv kom tiav thiab meej pab txhim kho koj cov txheej txheem kev yuav khoom thiab xyuas kom koj tau txais cov khoom zoo sib xws rau koj qhov project.
Hauv qab no yog cov ntaub ntawv tseem ceeb uas koj yuav tsum tau npaj rau kev hais lus thiab kev lees paub kev txiav txim:
- Khoom Qib: Qhia meej meej cov khoom qib: Inconel Alloy 601 (UNS N06601).
- Qhov ntev: Muab cov phaj tsis suav nrog cov thickness, dav thiab ntev.
- Ntau: Qhia qhov yuav tsum tau muaj kom tau txais cov lus hais raug raug.
- Cov ntaub ntawv technical: Muab cov kev qhia tshwj xeeb los yog kos duab. Txuas cov duab kos kom ntxaws yog tias koj muaj kev xav tau tshwj xeeb txog kev tsim qauv.
- Kev Ua Zoo & Kev Ntsuam Xyuas Cov Cai: Txhais cov qauv siv tau thiab cov ntsiab lus tshuaj xyuas, xws li kev tshuaj xyuas thib peb, daim ntawv pov thawj cov khoom siv thiab cov ntaub ntawv tshuaj xyuas.
- Cov Khoom Siv Tshwj Xeeb: Nco ntsoov cov kev xav tau ntxiv rau qhov ua tiav, polishing, kev ua haujlwm corrosion thiab lwm yam kev kho.
- Ntim Cov Lus Qhia: Hais txog cov kev xav tau ntim tshwj xeeb yog tias tsim nyog, piv txwv li kev tiv thaiv corrosion lossis tiv thaiv kev ntim khoom.
- Tus me nyuam Paub meej: Paub meej tias koj xav tau lub sij hawm ua ntej thiab qhov chaw xa khoom.
Nrog rau tag nrho cov ntsiab lus saum toj no tau npaj tau zoo, koj tuaj yeem ua kom yooj yim rau tag nrho cov khoom ua haujlwm thiab lav koj tau txais kev tsim nyog Inconel Alloy 601 phaj uas haum rau koj qhov project.
FAQ:
Inconel® 601 (Alloy 601) yog dab tsi?
Inconel® 601 (Alloy 601) yog npib tsib xee -chromium- hlau superalloy txhim kho nrog txhuas rau tshwj xeeb kub thiab oxidation kuj.
Dab tsi yog qhov txawv ntawm Inconel 600 thiab Inconel 601?
Inconel 600 thiab Inconel 601 yog ob qho tib si npib tsib xee -chromium- hlau alloys, tab sisInconel 601 muaj aluminium ntxiv, uas muab nws zoo dua siab -kub oxidation tsis kam tshaj Inconel 600.
Puas yog alloy 600 thiab Inconel 600 tib yam?
Yog lawm, Alloy 600 thiab Inconel 600 yog cov khoom siv tib yam, nrog "Inconel" yog lub npe lag luam thiab "Alloy 600" yog lub npe hu ua UNS (N06600).
Puas yog Inconel suav tias yog stainless hlau?
Tsis yog, Inconel tsis suav tias yog stainless hlau; nws yog anickel-raws li superalloy.
Vim li cas Inconel thiaj li nyuaj rau weld?
Inconel yog ib qho nyuaj rau weld vim nws cov ntsiab lus nickel thiab chromium siab ua rau lub pas dej khov, khov kho uas tiv taus ntws sib npaug, thaum nws tsis tshua muaj thermal conductivity ntxiab cua sov thiab ua rau thermal distortion lossis tawg.
