Alloy 602CA / 2.4633
Raws li tus neeg muag khoom thiab chaw tsim khoom nyob rau hauv Suav teb, GNEE Steel muab tus nqi -nickel zoo- raws li cov khoom siv alloy.
- Xa E-mail:ss@gneesteel.com
- Tel:+8615824687445
2.4633 yog ib lub siab carbon chromium-hlau-nickel alloy uas tseem muaj cov additives ntawm microalloy ntsiab titanium, zirconium thiab txhuas, thiab yttrium. Alloy 602CA yog tus cwj pwm los ntawm:
- zoo heev kub creep zog
- Kev qaug zog zoo heev hauv HCF thiab LCF hom
- txawv tshaj plaw oxidation kuj nyob rau hauv siab kub thiab nyob rau hauv cyclic tej yam kev mob.
Cov ntaub ntawv ntaub ntawv
| Khoom Siv Lub Npe | 2.4633 |
| Alloy | Alloy 602 CA |
| EN Cov Khoom Siv Cim | NiCr25FeAIY |
| UNS | N 06025 |
| Cov cim lag luam | Nicrofer® 6025 HT |
| VdTÜV Data Sheet | 540 |
| Ib txwm | DIN EN 10302 |
Cov teb tseem ceeb ntawm kev siv cov hlau 602CA
Alloy 602 yog ntau yam. Cov ntawv thov ntawm Alloy 602CA yog, piv txwv li:
- Rotary kiln thiab ncej
- Rauv chais / qhov cub qhov chaw
- nozzles
- cov yeeb nkab txhawb nqa
- Cheebtsam hauv cov pa purifying catalyst ntawm tsheb
- Reformers nyob rau hauv cov tshuaj thiab petrochemical kev lag luam
- Hydrogen ntau lawm
- Cua sov plugs
Tshuaj muaj pes tsawg leeg ntawm alloy 602CA
| C | Si | Mn | P | S | Cr |
| Tsawg dua los yog sib npaug li % | Tsawg dua los yog sib npaug li % | Tsawg dua los yog sib npaug li % | Tsawg dua los yog sib npaug li % | Tsawg dua los yog sib npaug li % | % |
| 0.15-0.25 | 0.5 | 0.5 | 0.02 | 0.01 | 24.0-26.0 |
| Al | Zr | Ti | Cu | Fe | Y | Ni |
| % | % | % | Tsawg dua los yog sib npaug li % | Tsawg dua los yog sib npaug li % | Tsawg dua los yog sib npaug li % | % |
| 1.8-2.4 | 0.01-0.1 | 0.1-0.2 | 0.1 | 8.11 | 0.05-0.12 | So |
Cov yam ntxwv ntawm alloy 602CA
| Qhov kub thiab txias | High-Temperature Range |
| Qhov ntom | 7.9 g / cm³ |
| ISO-V kev cuam tshuam toughness | lengthwise 69 J / cm² ntawm chav tsev kub |
| hla 56 J / cm² ntawm chav tsev kub |
Filler hlau (rau vuam nrog alloy 602CA)
Alloy 602CA tuaj yeem welded siv 2.4649 thiab DIN EN ISO 18274: S Ni 6025 ua hlau muab tub lim
Npog electrodes: DIN EN ISO 1412: E Ni 6025
UNS W86025
AWS A5.11: ENiCrFe-12
Kev pab cuam xa khoom
Ntawv / phaj mm
2 - 20
Coils mm
2
Bars / Billets dia. mm
20 - 35
Nrog rau lub sijhawm luv luv:
daim hlau los yog nplooj ntawv, raj, flanges, forged los yog tuag-txiav rings thiab round blanks, luj tshib, T-fittings, txo, screws, ceev los yog washers raws li koj thov. Raws li koj tus kheej xav tau, peb muaj peev xwm txiav peb cov khoom nrog peb cov plasma- los yog dej dav hlau cutter. Peb cov khoom yog stocked nyob rau hauv superformats ntawm 2000x6000mm. Txiav rau qhov loj me ntawm kev thov.
FAQ
Q: Koj tswj qhov zoo li cas?
A: Mill Test Certification yog muab nrog cov khoom xa tuaj, Kev Tshawb Fawb Thib Peb muaj. thiab peb kuj tau txais ISO, SGS, Alibaba Verified.
Q: Dab tsi yog qhov zoo ntawm koj lub tuam txhab?
A: Peb muaj ntau tus kws tshaj lij, cov kws tshaj lij, cov nqi sib tw thiab cov kev pabcuam zoo tshaj plaws tomqab muag ntau dua li lwm cov tuam txhab stainless hlau.
Q: Muaj pes tsawg coutries koj twb exported?
A: Exported rau ntau tshaj 50 lub teb chaws feem ntau yog los ntawm America, Russia, UK, Kuwait, Egypt, Qaib ntxhw, Jordan, Is Nrias teb, thiab lwm yam.
Q: Koj puas tuaj yeem muab cov qauv?
A: Yog. Peb tuaj yeem muab cov qauv me me hauv Tshuag dawb, tsuav yog koj tiv tauj peb. Cov qauv customized yuav siv li ntawm 5-7 hnub.
Cim npe nrov: Alloy 602ca / 2.4633, Tuam Tshoj alloy 602ca / 2.4633 lwm tus neeg
