Inconel Alloy 600 Forgings
Gnee pab pawg muaj Nickel Alloy Inconel 600 hauv ntau hom ntawv, suav nrog:
Tuav
Xov
Daim ntawv
Zam txim
Txoj hau
Flanges
Seamless thiab welded kav
Vuam Rods
Raws li tus neeg muag khoom thiab chaw tsim khoom nyob rau hauv Suav teb, GNEE Steel muab tus nqi -nickel zoo- raws li cov khoom siv alloy.
- Xa E-mail:ss@gneesteel.com
- Tel:+8615824687445
Inconel Alloy 600 Forgings Cov Lus Qhia
Inconel Alloy 600 Forgings
Inconel 600 Forgingsyog sib cuam tshuam los ntawm feem ntau nruab nrab thiab alkaline ntsev kev daws teeb thiab yog txawm siv hauv qee qhov chaw ib puag ncig. Nws tiv thaiv chav thiab cov sib xyaw ua ke ntawm cov chav, huab cua, thiab carbon dioxide. Qhov no alloy tsis yog kev sib nqus, muab cov khoom nqus, muab kev sib xyaw ua ke nrog kev ua haujlwm zoo, ua rau nws yooj yim weldable. Nws ua qauv qhia kom cov yam ntxwv txias feem ntau cuam tshuam nrog chromium-npib tsib xee stainless hlau. Nws muaj qhov zoo tshaj plaws tsis kam tshaj li Nickel 200 thiab 201 hauv oxidizing tej yam kev mob thiab muab cov ntsiab lus tsis zoo rau nws cov ntsiab lus uas muaj txiaj ntsig txog Nickel. Nws ua kom pom zoo zoo rau cov dej siab heev siv nyob rau hauv cov kev siv hluav taws xob nuclear thiab kev ua tau zoo rau cov ntsuas kub.
Thaum ua haujlwm nrogInco 600 Forgings, Nws yog qhov tsim nyog tau txais txiaj ntsig tias nws cov machinility yog qhov pom tseeb me me, kom pom tseeb. Lub alloy yog weldable, nrog roj tungsten arc vuam cov txheej txheem yog cov txhawb tshaj plaws. Raws li rau kev kho cua sov, 600 incmel feem ntau undergoes anevealing thiab daws kev kho mob. Thaum forging, qhov kub feem ntau yog li ntawm 2100 mus rau 1900 ºF (1150 txog 1040 ºC). Txawm li cas los xij, kev tswj hwm kub ceevfaj yog qhov tseem ceeb ntawm qee theem hauv kev forging txheej txheem, xav tias qhov tsis txaus ntseeg 600 tej zaum yuav raug rau oxidation thiab tawg.
Ntawm GNee Steel Group, peb cov paj ntaub kev cai kev cai folled cov khoom siv uas siv tau inconel 600 alloy. Tag nrho peb cov khoom sib ntsibAms 5665Cov lus qhia tshwj xeeb, thiab koj tuaj yeem tau txais lawv raws li cov tuav, discs, shafts lossis ib ncig. Peb tsuas yog siv dab tsi uas pom zoo los ntawmASTM Txuj Ci B564Cov. Peb cov cuab yeej siv niaj hnub no cia peb ua cov neeg ua haujlwm ua haujlwm cia peb ua cov khoom lag luam uas muaj kev lag luam thoob ntiaj teb kev ntseeg siab. Lawv pom cov ntawv thov hauv ntau kev lag luam, suav nrog kev ua zaub mov noj thiab tshuaj kho cua sov, thiab lwm yam.
Inconel 600 Forging Tshuag thiab muab ntau
Inconel 600 Forgings Specification
| Cov lus qhia | ASTM B564, ASME SB564, AMS 5665 |
|---|---|
| Lub hom phiaj | BS {3072-3076 (Na14) Din 17750, Din 17754 Werkstoff NR 2.4816 TÜV 305 AFM, ASTM, BS thiab txhua tus qauv thoob ntiaj teb |
| Tiaj Tus Thaiv Thaiv | Txog li 27 "dav thiab 15, 000 lbs |
| Cov thooj voos kheej kheej thiab tes tsho | Txog li 50 "ntau tshaj Od thiab 65" qhov ntev tshaj plaws |
| Discs thiab Cov Chaw Ntxuav | Txog li 50 "txoj kab uas hla thiab 20, 000 lbs |
| Dov, txhais tes forged lossis mandrel forged rings | txog 84 "ntau tshaj Od thiab 40" qhov ntev tshaj plaws |
| Rounds, Shafts thiab Theem Shafts | txog li 144 "qhov ntev tshaj plaws thiab 20, 000 lbs |
| Forging hom | Kev txiav txim siab tuag, qhib kev tuag, kev lom zem tsis quav ntsej, kub ntxhov, kub ntxhov, ua rau muaj kev zam txim rau, COMPERTION, rotary forging. |
Inconel 600 Forgings sib npaug qib
| Lub hom phiaj | Werkstoff NR. | Tsis yog | JIS | Bs | Gost | Ib tug kaum | En |
| Inconel 600 | 2.4816 | N06600 | NCF 600 | Na 13 | МНЖМц 28-2,5-1,5 | NC15fe11m | Nicr15fe |
Inconel 600 Tshuaj lom neeg muaj pes tsawg leeg rau kev zam txim
| Teem nqi | C | Mn | Si | S | CU | Zaum fe | Ni | Cr |
| Inconel 600 | 0. 15 max | 1. {00 max | 0. 50 Max | 0. 015max | 0. 50 Max | 6.00 – 10.00 | 72. {{{}} Min | 14.00 – 17.00 |
Cov khoom siv neeg kho tshuab ntawm inconel 600 kev zam txim
| Lub ntsiab | Ceev | Melting taw tes | Lub zog tensile | Paib lub zog (0. 2% offset) | Elongation |
| Inconel 600 | 8.47 g / cm3 | 1413 Qib (2580 Qib F) | PSI - 95, 000}}, mpa - 655 | PSI - 45, 000}, mpa - 310 | 40 % |
Gnee Pab Pawg Hoobkas Ib puag ncig
Inconel Alloy 600 Forgings
Cov FAQ
Q: Ntev npaum li cas yog koj lub sijhawm khoom plig?
A: Feem ntau nws yog {{{{}}} hnub yog tias cov khoom nyob hauv Tshuag lossis nws yuav xav tau {{}}}}}} yog cov khoom yuav tsum tau customized.
Q: Koj puas muab cov qauv yog nws dawb lossis ntxiv?
A: Yog, peb tuaj yeem muab cov qauv pub dawb.
Q: Koj cov nqe lus ntawm kev them nyiaj yog dab tsi?
A: 20% them ua ntej thiab sib npaug pom B / L theej lossis 100% LC thaum pom.
